| -Vce Saturation (Max) @ Ib, Ic |
1.5V @ 6mA, 3A |
| -Power - Max |
5W |
| -Supplier Device Package |
12-SIP |
| -Part Status |
Active |
| -Manufacturer |
Sanken |
| -Family |
Transistors - Bipolar (BJT) - Arrays |
| -Current - Collector Cutoff (Max) |
10µA (ICBO) |
| -DC Current Gain (hFE) (Min) @ Ic, Vce |
2000 @ 3A, 4V |
| -Package / Case |
12-SIP |
| -Transistor Type |
3 NPN, 3 PNP Darlington (3-Phase Bridge) |
| -Current - Collector (Ic) (Max) |
5A |
| -Category |
Discrete Semiconductor Products |
| -Voltage - Collector Emitter Breakdown (Max) |
80V, 100V |
| -Mounting Type |
Surface Mount |
| -Operating Temperature |
150°C (TJ) |
| -Packaging |
Bulk |
