| -Height Above Board |
0.039" (1.00mm) |
| -Voltage Rating |
30V |
| -Cable End Type |
Tapered |
| -Features |
Zero Insertion Force (ZIF) |
| -FFC, FCB Thickness |
0.20mm |
| -Category |
Connectors, Interconnects |
| -Contact Material |
Phosphor Bronze |
| -Number of Positions |
57 |
| -Mounting Type |
Surface Mount, Right Angle |
| -Locking Feature |
Flip Lock |
| -Material Flammability Rating |
UL94 HB |
| -Packaging |
Tape & Reel (TR) |
| -Current Rating |
0.2A |
| -Termination |
Solder |
| -Contact Finish |
Gold |
| -Flat Flex Type |
FPC |
| -Part Status |
Active |
| -Manufacturer |
Hirose Electric Co Ltd |
| -Housing Material |
Liquid Crystal Polymer (LCP) |
| -Series |
FH26 |
| -Family |
FFC, FPC (Flat Flexible) Connectors |
| -Operating Temperature |
-55°C ~ 85°C |
| -Connector/Contact Type |
Contacts, Bottom |
| -Pitch |
0.012" (0.30mm) |
| -Actuator Material |
Polyamide (PA), Nylon |
