| -Mounting Hole Diameter | 0.050" ~ 0.054" (1.27mm ~ 1.37mm) |
| -Contact Finish | Tin |
| -Length - Above Board | 0.156" (3.96mm) |
| -Flange Diameter | 0.072" (1.83mm) |
| -Staking Side ID | 0.039" (1.00mm) |
| -Manufacturer | Harwin Inc. |
| -Contact Material | Brass Alloy |
| -Insulation | Non-Insulated |
| -Mounting Type | Through Hole |
| -Termination | Swage |
| -Board Thickness | 0.063" (1.60mm) |
| -Terminal Type | Single End, Fork, Hollow |
| -Part Status | Active |
| -Number of Turrets | Single |
| -Category | Connectors, Interconnects |
| -Length - Overall | 0.238" (6.04mm) |
| -Family | Terminals - Turret Connectors |
| -Length - Below Flange | 0.082" (2.08mm) |
