| -Termination | Solder Pads |
| -Impedance | 2.2 kOhm |
| -Seal Rating | None |
| -Direction | Omnidirectional |
| -Size / Dimension | 9.70mm Dia |
| -Shape | Circular |
| -Manufacturer | Soberton Inc. |
| -Voltage - Rated | 4.5V |
| -Series | EM |
| -Height (Max) | 4.50mm |
| -Current - Supply | 500µA |
| -Sensitivity | -46dB ±2dB @ 94dB SPL |
| -Type | Electret Condenser |
| -S/N Ratio | 58dB |
| -Voltage Range | 1 ~ 10V |
| -Part Status | Active |
| -Category | Audio Products |
| -Output Type | Analog |
| -Port Location | Top |
| -Family | Microphones |
| -Frequency Range | 100Hz ~ 10kHz |
| -Packaging | Tray |
