| -Body Material |
Brass |
| -Manufacturer |
MPD (Memory Protection Devices) |
| -Mounting Type |
Chassis Mount |
| -Packaging |
Bulk |
| -Internal Switch(s) |
Single Switch, Normally Closed |
| -Number of Positions/Contacts |
2 Conductors, 3 Contacts |
| -Category |
Connectors, Interconnects |
| -Voltage - Rated |
12VDC |
| -Gender |
Male |
| -Operating Temperature |
-15°C ~ 90°C |
| -Current Rating |
5A |
| -Includes |
3 pcs - 1 Connector, 1 Nut, 1 Washer |
| -Contact Material - Plating |
Silver |
| -Shielding |
Unshielded |
| -Termination |
Solder Eyelet(s) |
| -Mounting Feature |
Bulkhead - Front Side Nut |
| -Part Status |
Active |
| -Industry Recognized Mating Diameter |
2.10mm ID (0.083"), 5.50mm OD (0.217") |
| -Actual Diameter |
0.083" (2.10mm ID), 0.220" (5.60mm OD) |
| -Family |
Barrel - Power Connectors |
| -Connector Type |
Jack |
