| -Low Level Output Voltage: |
0.12 V |
| -High Level Output Voltage: |
15 V |
| -Sensing Method: |
Reflective |
| -Minimum Operating Temperature: |
- 40 C |
| -Ir - Reverse Current: |
0.01 uA |
| -Mounting Style: |
Through Hole |
| -Number of Channels: |
1 |
| -Length: |
12 mm |
| -Manufacturer: |
Omron |
| -Vr - Reverse Voltage: |
4 V |
| -Series: |
EE-SY410 |
| -Brand: |
Omron Electronics |
| -RoHS: |
Details |
| -Product Category: |
Optical Switches, Reflective, Photo IC Output |
| -Wavelength: |
870 nm |
| -Output Voltage: |
28 V |
| -Width: |
4.6 mm |
| -Sensing Distance: |
5 mm |
| -Pd - Power Dissipation: |
250 mW |
| -Height: |
4.8 mm |
| -Vf - Forward Voltage: |
1.2 V |
| -Fall Time: |
3 us |
| -If - Forward Current: |
20 mA |
| -Output Type: |
Open Collector, Inverter |
| -Operating Supply Voltage: |
4.5 V to 16 V |
| -Factory Pack Quantity: |
500 |
| -Part # Aliases: |
1173631 367554 EESY410NC |
| -Low Level Output Current: |
16 mA |
| -Rise Time: |
20 us |
| -Maximum Operating Temperature: |
+ 75 C |
