| -Contact Form | SPST-NO (1 Form A) |
| -Turn Off Voltage (Min) | 0.5 VDC |
| -Operate Time | 10ms |
| -Coil Type | Non Latching |
| -Part Status | Obsolete |
| -Coil Current | 72mA |
| -Release Time | 5ms |
| -Contact Material | Silver Tin Oxide (AgSnO) |
| -Series | G5LA |
| -Coil Voltage | 5VDC |
| -Mounting Type | Through Hole |
| -Operating Temperature | -40°C ~ 85°C |
| -Coil Power | 360 mW |
| -Termination Style | PC Pin |
| -Turn On Voltage (Max) | 3.75 VDC |
| -Features | Insulation - Class F, Sealed - Flux Protection |
| -Category | Relays |
| -Manufacturer | Omron Electronics Inc-EMC Div |
| -Switching Voltage | 250VAC, 24VDC - Max |
| -Relay Type | General Purpose |
| -Coil Resistance | 69 Ohms |
| -Family | Power Relays, Over 2 Amps |
| -Contact Rating (Current) | 10A |
| -Packaging | Tray |
