| -Termination |
Solder |
| -Number of Positions Loaded |
All |
| -Part Status |
Obsolete |
| -Manufacturer |
Hirose Electric Co Ltd |
| -Number of Positions |
20 |
| -Mounting Type |
Through Hole, Right Angle |
| -Connector Type |
Receptacle, Female Sockets |
| -Material Flammability Rating |
UL94 V-0 |
| -Packaging |
Tray |
| -Current Rating |
2A |
| -Material - Insulation |
Polybutylene Terephthalate (PBT) |
| -Contact Finish |
Gold |
| -Category |
Connectors, Interconnects |
| -Series |
PCN10 |
| -Family |
Backplane Connectors - DIN 41612 |
| -Operating Temperature |
-55°C ~ 85°C |
| -Contact Finish Thickness |
8µin (0.20µm) |
| -Pitch |
0.100" (2.54mm) |
| -Number of Rows |
2 |
