| -SCR Type |
Standard Recovery |
| -Current - On State (It (AV)) (Max) |
3.8A |
| -Standard Package |
1,000 |
| -Current - Gate Trigger (Igt) (Max) |
15mA |
| -Voltage - On State (Vtm) (Max) |
1.6V |
| -Current - Off State (Max) |
10µA |
| -Family |
SCRs - Single |
| -Operating Temperature |
-40°C ~ 125°C |
| -Voltage - Off State |
200V |
| -Package / Case |
TO-202 Long Tab |
| -Supplier Device Package |
TO-202 |
| -Current - Non Rep. Surge 50, 60Hz (Itsm) |
83A, 100A |
| -Packaging |
Bulk |
| -Voltage - Gate Trigger (Vgt) (Max) |
1.5V |
| -Current - On State (It (RMS)) (Max) |
6A |
| -Mounting Type |
Through Hole |
| -Current - Hold (Ih) (Max) |
30mA |
