| -NEMA Frame Size |
23 |
| -Type |
Hybrid |
| -Accuracy |
±5% |
| -Step Angle |
1.8° |
| -Diameter - Shaft |
0.250" (6.35mm) |
| -Features |
Flatted Shaft |
| -Part Status |
Active |
| -Manufacturer |
NMB Technologies Corporation |
| -Voltage - Rated |
24VDC |
| -Coil Resistance |
5.8 Ohms |
| -Length - Shaft and Bearing |
0.984" (25.00mm) |
| -Torque - Holding (oz-in / mNm) |
67.98 / 480 |
| -Steps per Revolution |
200 |
| -Mounting Hole Spacing |
1.856" (47.14mm) |
| -Rotor Inertia |
120gcm² |
| -Termination Style |
Wire Leads with Connector |
| -Coil Type |
Unipolar |
| -Size / Dimension |
Square - 2.220" x 2.220" (56.40mm x 56.40mm) |
| -Category |
Motors, Solenoids, Driver Boards/Modules |
| -Weight |
1 lb (453.59g) |
| -Series |
23KM |
| -Family |
Stepper Motors |
| -Operating Temperature |
-10°C ~ 50°C |
| -Current Rating |
0.9A |
