| -Housing Material |
Thermoplastic |
| -Mounting Type |
Through Hole, Right Angle |
| -Termination |
Solder Eyelet(s) |
| -Internal Switch(s) |
Single Switch, Normally Closed |
| -Standard Package |
500 |
| -Color |
Black |
| -Voltage - Rated |
16VDC |
| -Gender |
Male |
| -RoHS Information |
PJ-035CH Cert of Compliance |
| -Connector Type |
Jack |
| -Current Rating |
3.5A |
| -Contact Material - Plating |
Nickel |
| -Shielding |
Unshielded |
| -Housing Color |
Black |
| -Catalog Drawings |
PJ-035, PJ-017 Schematic |
| -Number of Positions/Contacts |
2 Conductors, 3 Contacts |
| -Plug/Mating Plug Diameter |
1.1mm ID, 3.5mm OD |
| -Contact Material |
Brass |
| -Family |
Barrel - Power Connectors |
| -Operating Temperature |
-25°C ~ 85°C |
| -3D Model |
PJ-035CH |
