| -Material - Insulation |
Polybutylene Terephthalate (PBT) |
| -Number of Positions Loaded |
All |
| -Mounting Type |
Through Hole |
| -Termination |
Wire Wrap |
| -Standard Package |
26 |
| -Online Catalog |
PCN10 and PCN13 Series |
| -Series |
PCN10 |
| -Operating Temperature |
-55°C ~ 85°C |
| -Current Rating |
2A |
| -Pitch |
0.100" (2.54mm) |
| -Contact Finish |
Gold |
| -Style |
B |
| -Material Flammability Rating |
UL94 V-0 |
| -Catalog Drawings |
2 Row Socket Straight Top 2 Row Socket Straight Foot Print |
| -Packaging |
Tray |
| -Number of Positions |
50 |
| -Family |
Backplane Connectors - DIN 41612 |
| -Connector Type |
Receptacle, Female Sockets |
| -Number of Rows |
2 |
