| -Operating Temperature - Junction |
200°C (Max) |
| -Capacitance @ Vr, F |
4pF @ 0V, 1MHz |
| -Supplier Device Package |
DO-34 |
| -Standard Package |
5,000 |
| -Diode Type |
Standard |
| -Reverse Recovery Time (trr) |
20ns |
| -Family |
Diodes, Rectifiers - Single |
| -Voltage - DC Reverse (Vr) (Max) |
80V |
| -Current - Average Rectified (Io) |
200mA |
| -Package / Case |
DO-204AG, DO-34, Axial |
| -Catalog Drawings |
DO-34 Top 2 Pin Circuit |
| -Packaging |
Tape & Box (TB) |
| -Speed |
Small Signal =< 200mA (Io), Any Speed |
| -Current - Reverse Leakage @ Vr |
500nA @ 75V |
| -Mounting Type |
Through Hole |
| -Voltage - Forward (Vf) (Max) @ If |
1.1V @ 200mA |
