| -Operating Temperature - Junction |
125°C (Max) |
| -Capacitance @ Vr, F |
9pF @ 0V, 1MHz |
| -Supplier Device Package |
SSSMini2-F3 |
| -Standard Package |
1 |
| -Diode Type |
Schottky |
| -Reverse Recovery Time (trr) |
1ns |
| -Family |
Diodes, Rectifiers - Single |
| -Voltage - DC Reverse (Vr) (Max) |
30V |
| -Current - Average Rectified (Io) |
100mA |
| -Package / Case |
2-SMD, Flat Lead |
| -Catalog Drawings |
SSS Mini Type 2 Pin Top |
| -Packaging |
Cut Tape (CT) |
| -Speed |
Small Signal =< 200mA (Io), Any Speed |
| -Current - Reverse Leakage @ Vr |
2µA @ 30V |
| -Mounting Type |
Surface Mount |
| -Voltage - Forward (Vf) (Max) @ If |
580mV @ 100mA |
