L04021R0AHN

FIXED IND 1NH 500MA 150 MOHM SMD

Manufacturer AVX Corporation MPN L04021R0AHN SPQ 5000 ECCN -- Schedule B -- RoHS -- Datasheet --

Quote

Demand quantity		Target price
Contact number		name
company		email

Product parameter

-Tolerance	±0.05nH
-Package / Case	0402 (1005 Metric)
-Supplier Device Package	0402 (1005 Metric)
-Standard Package	5,000
-Size / Dimension	0.039" L x 0.023" W (1.00mm x 0.58mm)
-Height - Seated (Max)	0.018" (0.45mm)
-Series	L0402
-Mounting Type	Surface Mount
-DC Resistance (DCR)	150 mOhm Max
-Frequency - Test	450MHz
-Inductance	1nH
-Type	Thin Film
-Frequency - Self Resonant	20GHz
-Q @ Freq	20 @ 450MHz
-Packaging	Tape & Reel (TR)
-Material - Core	Non-Magnetic
-Family	Fixed Inductors
-Shielding	Unshielded
-Current Rating	500mA
