| -PCN Obsolescence/ EOL |
Multiple Devices 28/Aug/2013 |
| -Size / Dimension |
3.00mm L x 2.00mm W |
| -Current - Test |
20mA |
| -Mounting Type |
Surface Mount, Right Angle |
| -Lens Transparency |
Clear |
| -Package / Case |
2-SMD, No Lead |
| -Standard Package |
1 |
| -Packaging |
Cut Tape (CT) |
| -Voltage - Forward (Vf) (Typ) |
1.9V |
| -Series |
1101F |
| -Viewing Angle |
140°, 130° |
| -Lens Style/Size |
Rectangle with Domed Top, 2.00mm x 1.00mm |
| -Wavelength - Peak |
609nm |
| -Height (Max) |
1.00mm |
| -Millicandela Rating |
65mcd |
| -Catalog Drawings |
1101F-TR Series Top 1101F-TR Series Side |
| -Color |
Orange |
| -Lens Color |
Colorless |
| -Wavelength - Dominant |
605nm |
| -Family |
LED Indication - Discrete |
