| -Switch Function | Off-Mom |
| -PCN Obsolescence/ EOL | EVQ-P7, P3 Series 17/Jun/2013 |
| -Operating Force | 160gf |
| -Circuit | SPST-NO |
| -Contact Rating @ Voltage | 0.05A @ 12VDC |
| -Standard Package | 1 |
| -Packaging | Digi-Reel® |
| -Switch Travel | 0.20mm |
| -Mechanical Life | 100,000 Cycles |
| -Outline | 3.50mm x 2.90mm |
| -Actuator Orientation | Side Actuated |
| -Termination Style | J Lead |
| -Mounting Type | Surface Mount, Right Angle |
| -Actuator Type | Rectangular Button |
| -Catalog Drawings | SMD Circuit 1 Right Angle Low Profile J-Bent leads_1.35 x 3.5 EVQ-P7(D,M)01K Footprint |
| -Features | Board Guide |
| -Illumination | Non-Illuminated |
| -Series | EVQP7 |
| -Family | Tactile Switches |
| -Operating Temperature | -20°C ~ 70°C |
