| -Voltage - Isolation |
5000Vrms |
| -Current - Output / Channel |
50mA |
| -Current Transfer Ratio (Min) |
63% @ 10mA |
| -Packaging |
Tube |
| -Voltage - Output (Max) |
70V |
| -Output Type |
Transistor with Base |
| -Rise / Fall Time (Typ) |
3µs, 14µs |
| -Current - DC Forward (If) (Max) |
60mA |
| -Mounting Type |
Through Hole |
| -Operating Temperature |
-55°C ~ 110°C |
| -Package / Case |
6-DIP (0.300", 7.62mm) |
| -Supplier Device Package |
6-DIP |
| -Standard Package |
2,000 |
| -Turn On / Turn Off Time (Typ) |
4.2µs, 23µs |
| -Number of Channels |
1 |
| -Voltage - Forward (Vf) (Typ) |
1.39V |
| -Current Transfer Ratio (Max) |
125% @ 10mA |
| -Family |
Optoisolators - Transistor, Photovoltaic Output |
| -Vce Saturation (Max) |
400mV |
| -Input Type |
DC |
