| -Housing Color |
Gray |
| -Style |
Side Entry |
| -Standard Package |
20 |
| -Packaging |
Bulk |
| -Housing Material |
Polyamide (PA), Nylon |
| -Family |
Heavy Duty Connectors - Housings, Hoods, Bases |
| -Connector Type |
Base - Panel Mount 90° |
| -Size |
A3/4 |
| -For Use With |
C146 10A003 002 4-ND - INSERT MALE 3POS+1GND SCREW C146 10A004 002 4-ND - INSERT MALE 4POS+1GND SCREW C146 10B003 002 4-ND - INSERT FEMALE 3POS+1GND SCREW C146 10B004 002 4-ND - INSERT FEMALE 4POS+1GND SCREW |
| -Ingress Protection |
IP65 - Dust Tight, Water Resistant |
| -Size / Dimension |
1.575" L x 1.094" W x 1.024" H (40.00mm x 27.80mm x 26.00mm) |
| -Lock Location |
Central Locking Clip on Base Bottom |
| -Series |
heavy|mate®, C146 A |
| -Operating Temperature |
-40°C ~ 100°C |
| -Thread Size |
PG11 |
