| -Operating Temperature - Junction |
-65°C ~ 175°C |
| -Capacitance @ Vr, F |
50pF @ 0V, 1MHz |
| -Supplier Device Package |
MELF |
| -Packaging |
Cut Tape (CT) |
| -Speed |
Fast Recovery =< 500ns, > 200mA (Io) |
| -Current - Reverse Leakage @ Vr |
1µA @ 100V |
| -Mounting Type |
Surface Mount |
| -Voltage - Forward (Vf) (Max) @ If |
980mV @ 1A |
| -Current - Average Rectified (Io) |
850mA |
| -Package / Case |
SOD-87 |
| -Standard Package |
1 |
| -Diode Type |
Avalanche |
| -Reverse Recovery Time (trr) |
25ns |
| -Family |
Diodes, Rectifiers - Single |
| -Voltage - DC Reverse (Vr) (Max) |
100V |
