| -Switch Function | Off-Mom |
| -Actuator Height off PCB, from Pins | 4.30mm |
| -Other Related Documents | How to Read Date Codes |
| -Mounting Type | Through Hole |
| -Actuator Type | Standard |
| -Standard Package | 1 |
| -Illumination | Non-Illuminated |
| -Mechanical Life | 100,000 Cycles |
| -Family | Tactile Switches |
| -Operating Temperature | -25°C ~ 70°C |
| -Actuator Orientation | Top Actuated |
| -Termination Style | PC Pin |
| -Operating Force | 260gf |
| -Circuit | SPST-NO |
| -Contact Rating @ Voltage | 0.05A @ 24VDC |
| -Packaging | Cut Tape (CT) |
| -Switch Travel | 0.25mm |
| -Series | B3F |
| -Outline | 6.00mm x 6.00mm |
