| -Voltage - Isolation | 3kV (3000V) |
| -Type | Constant Current |
| -Ratings | IP66 |
| -Current - Output (Max) | 4A |
| -Termination Style | Wire Leads |
| -Approvals | CE, CSA, EN, UL |
| -Size / Dimension | 9.49" L x 1.70" W x 1.36" H (241.0mm x 43.0mm x 34.5mm) |
| -Weight | 1.1 lbs (499g) |
| -Series | ALC100 |
| -Family | LED Supplies |
| -Mounting Type | Chassis Mount |
| -Number of Outputs | 1 |
| -PCN Obsolescence/ EOL | ALC and ALV Series 01/Aug/2013 |
| -Topology | AC DC Converter |
| -Standard Package | 5 |
| -Voltage - Output | 6 ~ 22 V |
| -Features | OVP, SCP |
| -Efficiency | 86% |
| -Voltage - Input (Max) | 305VAC |
| -Power (Watts) | 88W |
| -Voltage - Input (Min) | 90VAC |
| -Operating Temperature | -30°C ~ 70°C |
