| -Product Training Modules | Fan Options |
| -Other Related Documents | Part Number Break-Down and Other Notes |
| -Air Flow | 42.0 CFM (1.19m³/min) |
| -Life Expectancy | 70000 hrs @ 40°C |
| -Bearing Type | Ball |
| -Termination | 3 Wire Leads |
| -Material - Blade | Plastic |
| -Features | Locked Rotor Sensor |
| -Voltage - Rated | 24VDC |
| -Series | AFB |
| -RPM | 3600 RPM |
| -Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| -Size / Dimension | Square - 80mm L x 80mm H x 25.4mm W |
| -Material - Frame | Plastic |
| -Weight | 0.176 lb (79.83g) |
| -Power (Watts) | 3.36W |
| -Fan Type | Tubeaxial |
| -Static Pressure | 0.217 in H2O (54.1 Pa) |
| -Standard Package | 135 |
| -Voltage Range | 14 ~ 27.6VDC |
| -Noise | 38 dB(A) |
| -Family | DC Fans |
| -RoHS Information | DC Fans RoHS Cert of Compliance |
| -Current Rating | 0.140A |
