| -Release Force | 5gf |
| -PCN Obsolescence/ EOL | ABJ x(6,7,8)xx Feb/2012 |
| -Termination Style | PC Pin |
| -Other Related Documents | How to Read Date Codes |
| -Mounting Type | Through Hole |
| -Actuator Type | Lever, Simulated Roller |
| -Pretravel | 0.120" (3.0mm) |
| -Voltage Rating - AC | 125V |
| -Packaging | Bulk |
| -Series | ABJ |
| -Operating Temperature | -40掳C ~ 85掳C |
| -Current Rating | 100mA (AC) |
| -Switch Function | On-Mom |
| -Ingress Protection | IP50 - Dust Protected |
| -Electrical Life | 6,000 Cycles |
| -Operating Position | 0.386" (9.8mm) |
| -Circuit | SPDT |
| -Differential Travel | 0.020" (0.5mm) |
| -Standard Package | 100 |
| -Operating Force, Torque | 65gf |
| -Mechanical Life | 1,000,000 Cycles |
| -Family | Snap Action, Limit Switches |
| -Overtravel | 0.020" (0.5mm) |
