| -Conductor Strand |
Solid |
| -Cable Type |
Coaxial |
| -Product Training Modules |
Basics of Wire and Cable |
| -Jacket (Insulation) Diameter |
0.242" (6.15mm) |
| -Wire Gauge |
22 AWG |
| -Alternate Length |
9062AC BK021-ND - CABLE COAXIAL RG62A 22AWG 1000' 9062AC BK011-ND - CABLE COAXIAL RG62A 22AWG 2000' 9062AC BK001-ND - CABLE COAXIAL RG62A 22AWG 1000' 9062AC BK005-ND - CABLE COAXIAL RG62A 22AWG 100' |
| -Dielectric Material |
Solid Polyethylene (PE) |
| -Jacket (Insulation) Material |
Poly-Vinyl Chloride (PVC) |
| -Family |
Coaxial Cables (RF) |
| -Conductor Material |
Steel, Copper Coated |
| -Operating Temperature |
-20°C ~ 80°C |
| -Impedance |
93 Ohm |
| -Dielectric Diameter |
0.146" (3.71mm) |
| -Cable Group |
RG-62A |
| -Shield Type |
Braid |
| -Shield Coverage |
95% |
| -Standard Package |
1 |
| -Color |
Black |
| -Length |
500' (152.44m) |
| -Shield Material |
Copper, Bare |
| -VoP, Velocity of Propagation |
83 |
