| -Voltage Rating |
125V |
| -PCN Packaging |
FCP Reel 01/Apr/2014 |
| -Housing Material |
Polyphenylene Sulfide (PPS) |
| -Connector/Contact Type |
Contacts, Bottom |
| -Material Flammability Rating |
UL94 V-0 |
| -Height Above Board |
0.118" (3.00mm) |
| -Cable End Type |
Tapered |
| -Standard Package |
1,500 |
| -Packaging |
Tape & Reel (TR) |
| -Series |
WR-FPC |
| -Family |
FFC, FPC (Flat Flexible) Connectors |
| -3D Model |
6861xx14422.pdf 68611814422.igs 68611814422.stp 68611814422.wrl |
| -Current Rating |
1A |
| -Contact Finish |
Tin |
| -FFC, FCB Thickness |
0.29mm ~ 0.34mm |
| -Mounting Type |
Surface Mount, Right Angle |
| -Locking Feature |
Slide Lock |
| -Actuator Material |
Polyphenylene Sulfide (PPS) |
| -Termination |
Solder |
| -Flat Flex Type |
FPC |
| -Features |
Solder Retention, Zero Insertion Force (ZIF) |
| -Contact Material |
Phosphor Bronze |
| -Number of Positions |
18 |
| -Operating Temperature |
-25°C ~ 85°C |
| -Pitch |
0.039" (1.00mm) |
