| -Height Above Board |
0.087" (2.20mm) |
| -Voltage Rating |
100V |
| -Cable End Type |
Straight |
| -Features |
Solder Retention, Zero Insertion Force (ZIF) |
| -FFC, FCB Thickness |
0.30mm |
| -Category |
Connectors, Interconnects |
| -Contact Material |
Phosphor Bronze |
| -Number of Positions |
16 |
| -Mounting Type |
Surface Mount, Right Angle |
| -Locking Feature |
Flip Lock |
| -Material Flammability Rating |
UL94 V-0 |
| -Packaging |
Tape & Reel (TR) |
| -Current Rating |
1A |
| -Termination |
Solder |
| -Contact Finish |
Tin |
| -Flat Flex Type |
FFC, FPC |
| -Part Status |
Active |
| -Manufacturer |
Wurth Electronics Inc |
| -Housing Material |
Polyamide (PA6T), Nylon 6T |
| -Series |
WR-FPC |
| -Family |
FFC, FPC (Flat Flexible) Connectors |
| -Operating Temperature |
-40°C ~ 105°C |
| -Connector/Contact Type |
Contacts, Bottom |
| -Pitch |
0.039" (1.00mm) |
| -Actuator Material |
Polyamide (PA6T), Nylon 6T |
