| -Connector Style |
D-Sub, High Density |
| -Contact Finish |
Gold |
| -Housing Material |
Polyamide (PA), Nylon, Glass Filled |
| -Contact Finish Thickness |
30µin (0.76µm) |
| -Contact Type |
Signal |
| -Standard Package |
50 |
| -Features |
Board Lock |
| -Packaging |
Tray |
| -Number of Positions |
26 |
| -Operating Temperature |
-55°C ~ 105°C |
| -3D Model |
17EBH-026-S-xx-0-10.igs 17EBH-026-S-xx-0-10.stp |
| -Number of Rows |
3 |
| -Shell Material, Finish |
Steel, Tin Plated |
| -Shell Size, Connector Layout |
2 (DA, A) High Density |
| -Mounting Type |
Through Hole, Right Angle |
| -Termination |
Solder |
| -Catalog Drawings |
17EBH Series |
| -Color |
Black |
| -Flange Feature |
Housing/Shell (Unthreaded) |
| -Series |
17EBH |
| -Family |
D-Sub Connectors |
| -Connector Type |
Receptacle, Female Sockets |
| -Current Rating |
3A |
