1478603-4

SWITCH LEVER SPDT 16A SLDR TERM

制造商 TE Connectivity 制造商零件编号 1478603-4 标准包装 1 ECCN -- Schedule B -- RoHS -- 规格说明书 --

询价

需求数量		目标价格
联系电话		姓名
公司		邮箱

产品参数

-Release Force	5gf
-Termination Style	Solder, Quick Connect - 0.187" (4.7mm)
-Operating Position	0.606" (15.4mm)
-Circuit	SPDT
-Differential Travel	0.094" (2.4mm)
-Pretravel	0.296" (7.5mm)
-Voltage Rating - AC	125V
-Packaging	Bulk
-Mechanical Life	10,000,000 Cycles
-RoHS Information	1478603-4 Statement of Compliance RoHS 2 Statement
-Overtravel	0.102" (2.6mm)
-Switch Function	On-Mom
-Electrical Life	100,000 Cycles
-Mounting Type	Chassis Mount
-Actuator Type	Lever, Straight
-Catalog Drawings	147 Series Microswitch 147 Series Microswitch Side 14786xx-4
-Standard Package	1
-Operating Force, Torque	30gf
-Series	Alcoswitch
-Family	Snap Action, Limit Switches
-Operating Temperature	-20°C ~ 130°C
-Current Rating	16A (AC)
